Catalog reference FW86
52-Inch × 8-Foot Tower — 6 ft Platform
52-Inch × 8-Foot Tower — 6 ft Platform, reference FW86. View catalog dimensions and the complete package component quantities.
Supplied catalog image, unchanged. Component photos may illustrate a product family; confirm exact dimensions in the specifications.
52-Inch Tower Packages / FW86
52-Inch × 8-Foot Tower — 6 ft Platform
Reference FW86. Frame width: 52 in; Bay length: 8 ft; Platform height: 6 ft.
Request a QuoteConfirm compatibility, complete system requirements and availability.
Technical overview
Product specifications
Catalog dimensions are reproduced in their original imperial units. Bay fit does not specify a brace’s physical length.
- Catalog code
- FW86
- Frame width
- 52 in
- Bay length
- 8 ft
- Platform height
- 6 ft
- Caster diameter
- 8 in
- Brace identification
- Diagonal: blue; horizontal: yellow; plan: red
- Illustrated overall length
- 8 ft 6 in
- Load capacity
- Not specified in catalog
- Weight
- Not specified in catalog
- Availability
- Confirm availability
Package components and quantities
| Component | Catalog reference | Quantity |
|---|---|---|
| 3 ft tall frames | W3 | 2 |
| 5 ft tall frames | W5 | 2 |
| Horizontal braces | H100 | 6 |
| Diagonal braces | D108 | 2 |
| Plan brace | PW8 | 1 |
| Hatch platforms | HP100 | 1 |
| Standard platforms | SP100 | 1 |
| 8 in casters | C8 | 4 |
| Outriggers | Not listed | Not listed |
| Toe board set | TBW8 | 1 |
Specification notes
Package quantities are from the 2025 catalog package table. “Not listed” preserves a blank catalog cell. Package references N3/N5 and W3/W5 correspond to individually listed FN3/FN5 and FW3/FW5 frames. C8 is the package caster reference; the individual caster is C8ADJ. Toe board package references omit the final S used by individual sets. The 52-inch table uses OLG for large outriggers; the individual large outrigger is OUT120. Confirm these reference mappings and stabilization requirements before ordering. Platform height is the standing platform elevation, not working height. More tower sizes are available upon request.
Browse 52-Inch Tower Packages →Browse all products →
Product questions
What specifications are available?
The specifications on this page reproduce the dimensions and references listed in the 2025 catalog. Dimensions and ratings not listed are identified explicitly.
How do I confirm compatibility?
Provide the catalog code and complete scaffold configuration when requesting a quote. Compatibility and availability require confirmation.
